Goulds 3196 ANSI Pump, ASME B73.1 Chemical Process Pump

G type ASME B73.1 Chemical Process Pump is equivalent to Goulds 3196 pump.
There are four kinds of material for your convenience, SS316, CD4M, CN7M and
Hastelloy CF8M, to meet different working condition request. Both of the two
types of pumps run outstanding hydraulic performance, supreme reliability,
lowest cost and very easy maintenance.

ANSI Pump Introduction
ANSI Pump is a common centrifugal pump that complies with the American
National Standards Institute (ANSI) and has the characteristics of high
efficiency, corrosion resistance, easy maintenance, wide application,
reliability and safety. ANSI Pumps are typically used to handle clean or
lightly contaminated fluids, such as water, chemicals, petroleum products,
etc., and are suitable for a variety of industrial and commercial applications.

ANSI Pump Specifications
● Capacities to 7000 GPM (1590 m 3 /h)
● Heads to 730 feet (223 m)
● Temperatures to 700F (371C)
● Pressures to 375 PSIG (26 bar)

ANSI Pump Features:
● Fully Open Impeller
● Heavy Duty Casing Design
● Engineered Seal Chambers
● Back Pull-out Design, easy maintenance
● External Impeller Adjustment

ANSI Pump Typical Applications
★ Chemical transfer
★ Petrochemical Processing
★ Brine
★ Puple & Paper
★ Food and Beverage Processing
★ Hydrocarbon
★ Pharmaceuticals
★ Primary Metals
★ Corrrosive Service

Available ANSI Pump- Goulds 3196 pump Size:
1x1.5-6 1.5x1-62
1x1.5-8 1.5x1-82
1.5x3-6 3x1.5-62
1.5x3-8 3x1.5-82
2x3-6 3x2-62
3x4-7 3x2-82
2x3-8 4x3-82
3x4-8 2x1-10A
3x4-8G 3x1.5-10
1x2-10 3x1.5-10A
1.5x3-10 3x2-10
2x3-10 3x2-10A
3x4-10 4x3-10
3x4-10H 4x3-10H
4x6-10 6x4-10
4x6-10H 6x4-10H
1.5x3-13 3x1.5-13
2x3-13 3x2-13
3x4-13 4x3-13
4x6-13 4x3-13HH
6x8-13 6x4-13A
8x10-13 8x6-14A
8x10-15 10x8-16
8x10-15G 10x8-16H
6x8-15 6x4-16
4x6-17 8x6-16
6x8-17 8x6-16A
8x10-17
