Product Description
Metal-beam guardrails are considered semi-rigid barriers, where the W-beam is
mounted to steel or timber posts. When impacted, they are designed to deform
and deflect, absorbing some of the crash energy and redirecting the vehicle.
Galvanized Highway W Beam Guardrail is designed to create a safe and secure
boundary along highways and roads, while providing an aesthetically pleasing
look. W Beam Guardrail is typically constructed from hot dipped galvanized
steel, which is a metal that provides a protective layer of coating to ensure
long-lasting use and protection against rust and corrosion. The W Beam design
is widely preferred because of the improved protection it offers from vehicular
impacts and its sleek, contemporary appearance.
By offering protection from several different angles, W Beam Guardrail can
reduce the severity of accidents involving automobiles. In addition, it directs
vehicles away from hazardous areas and keeps them from straying off the road.
Dachu Guardrail also has excellent visibility characteristics and can also be
used for aesthetic purposes.
Parameters of Galvanized Highway W Beam Guardrail
Guardrail Standard AASHTO M180
Totally Length 13'½"
Effective Length 12'6"
Base Steel thickness 10 Gauge and 12 Gauge;Can be customized
Material S355JR Steel
Yield Point Minimum 345Mpa (50000psi);
Tensile Strength Minimum 483Mpa (70000psi);
Surface Treatment Hot Dip Galvanized
Zinc Coating 1.8 oz./sq.ft and 3.6 oz./sq.ft;
Can be customized
Coat Standard ASTM A123
Unfinished Beam - to be painted Available
Corrosion Resistant Steel -weathering  Available
Free Sample Available
Curved W Beam Can be customized
