Fuji Samba G5L Printhead

The Samba G5L printhead technology delivers the speed, versatility and reliability required for a wide range of demanding graphics and specialty applications. The Samba printhead leverages the accuracy and precision of Silicon MEMS (Si-MEMS) processing with the reliability and life of sputtered PZT in an ingenious parallelogram shape to deliver breathtaking image quality at near analog production speeds.

With 2048 individually addressable nozzles, the Samba G5L printhead has 1,200 dpi native resolution (600 dpi in redundant mode) and a native ink drop size of 2.4 picoliters (pl) delivering outstanding print quality that can jet a wide range of fluids including latex, solvent and aqueous inks.
Specifications

Number of addressable Jets per module: 2048
Print width: 43mm (1.7 in.) per printhead, stitch for infinite print width
Native resolution: 1200 dpi/600 dpi in redundant mode
Native drop size/largest drop size: 3.5 pl to 13pl
Firing frequency: Up to 100Khz
Nominal fluid viscosity: 5 to 9 cPs
Compatible jetting fluids: AQ, Latex, Solvents, Other
Nozzle Plate technology: Silicon MEMS/ Non-wetting coating
Printhead heat type: Fluids thermal transfer
This printhead carries a manufacturer warranty.
Country of origin : Japan

Minimum Order: 1 pieces
