For Hydraulic Direct-Acting Relief Valve equivalent to SUN RDBA, AAK receiv

Last May, we launched a hydraulic direct-acting relief valve equivalent to SUN
standard part RDBA.

Direct-acting relief cartridges are normally closed, pressure-limiting valves
used to protect hydraulic components from pressure transients. When the
pressure at the inlet (port 1) reaches the valve setting, the valve starts to
open to tank (port 2), throttling flow to limit the pressure rise. These valves
are smooth and quiet, essentially zero leak, dirt tolerant, immune to silting
and are very fast.

2 months after it was posted, we received the trial order from a new client in
Spain. Per client, they will test the samples first. After it passed the
testing, they will place the re-peat order for 500 pcs.

Last week, it was 13 months after the trial order was delivered, we received
the re-peat order for 650 pcs from this Spanish client.

AAK hydraulic Direct-Acting Relief Valve 2 advantages:
1. The quality of this valve is benchmarking SUN, but price is much cheaper.
2. The service life is 2 times that of domestic hydraulic cartridge valve
manufacturers in China

Technical parameters of AAK E-RDBA Hydraulic Direct-Acting Relief Valve:
Max. Operating Pressure: 350 bar (5000 psi)
Flow: 45 lpm (12 gpm)
Max. Valve Leakage at Reseat: 10 drops/min. (0.7 cc/min.)
Response Time – Typical: 2 ms
Reseat: >85% of crack setting
Adjustment - No. of CW Turns from Min. to Max. setting: 6
Operating Fluid Temperature: - 40°C ~ + 100°C (with Standard Buna N seals)
Cavity: T-162A

AAK E-RDBA Hydraulic Direct-Acting Relief Valve, benchmarking SUN RDBA, its
service life is 2 times that of its domestic peers. You are welcome to give it
a try.
