Foot sensor device for electric tailgae lift system

Item No.: KMFS000

By installing a sensor at the rear of the vehicle and connecting it to the
signal wire of the original car’s rear trunk, when the car is unlocked and the
sensor senses that someone performs an unlocking action within a certain range,
the tailgate will aut
What is foot sensor (kick activated) device?
By installing a sensor at the rear of the vehicle and connecting it to the
signal wire of the original car’s rear trunk, when the car is unlocked and the
sensor senses that someone performs an unlocking action within a certain range,
it will automatically open or close the rear door.
Foot Sensor Device KaiMiao Accessory List:
Accessory Name Description
Package Size: 22.5*15.5cm
Weight: 0.36kg
Wire harness A: 1.8m
Wire harness B: 4m
Tips: 1
Wire clamp: 1
Fuse: 2
https://www.kmautospace.com/foot-sensor-p0042 , 5p1.html
Parameters:
Part Parameter Description
ECU Size: 66*36*26mm
Weight: 0.047kg
Operating Voltage Range: DC8 ~ 20V
Working Temperature Range: -30℃ ~ 75℃
Working Current: ≤14mA
Stand-by Current: ≤7.28mA
Power Reverse Connection Protection: YES
Short Circuit Protection: YES
Fuse Holder: 3A
Over Temperature Protection: 95℃
Waterproof Level: IP67
Sensor Detection Method: Millimeter Wave
Responding Speed: 100uS
Sensing Distance: 5-15cm
ACC System Detect ACC Power Consumption: Increase 2.28mA
Detection of ACC Method: The same chip detects status
ACC Detection Process: When ACC detects high power frequency, the host
does not output; when there is no high power frequency, the host outputs.
- Warranty: 1 year

Minimum Order: 1 sets
