Filter Press

HongVadar company provides you the Lysine, Tryptophan, Threonine, Valine,
Leucine, etc. fermentation products project. HongVader as agricultural
processing plants play the roles of corn, sweet corn processing plant, potato
processing plant, starch of corn and wheat processing plant, taking wheat,
rice, cassava processing, msg project, and production lines of ethanol glucose,
DMH, fructose, sorbitol.

HVD-FP-A fully automatic filter press is composed of a filter plate or filter
frame. The filter plate and the filter frame form a set of filter chambers in
the middle of press filter machine. The surface of the filter plate is grooved
and the protruding part is used to support the filter cloth. The filter frame
or filter plate has a through-hole in the corner, which forms a complete
channel after assembly, and can pass into the suspension, washing water, and
lead out the filtrate. Plate and frame filter press machine working like this:
each side of the filter plate or the filter frame has a handle supported on the
beam, and the filter plate or the filter frame is pressed down by a pressing
device. The filter cloth between the filter plate or between the filter plate
and the filter frame acts as a sealing gasket. The suspension fluid is pumped
into the filter chamber and formed on the filter cloth until the filter chamber
is fully filled. The filtrate passes through the filter cloth and flows along
the groove of the filter plate to the corner channel of the filter plate or
plate frame for centralized discharge. After filtration, the filter residue can
be washed with clean water. After washing, sometimes also through the
compressed air, remove the remaining washing liquid. Then open the diagram of
plate and frame filter press to remove the filter residue, clean the filter
cloth, press the filter plate again,
and start the next working cycle.

Features of Filter Press
The plate and filter press adopts the hydraulic device as the power device
for pressing and loosening the filter plate;
The upper part of the main beam is covered with 304 stainless steel, which
can effectively reduce the friction resistance between the filter plate and the
main beam and reduce the working strength;
The integrated hydraulic control system of plate frame filter press adopts
international famous brand components, hydraulic system valve body precision
processing, to ensure durable;
Membrane plate filter press adopts new raw materials and formula, high-
pressure molding, high strength, high working pres, high filtration efficiency,
no blocking, no breaking plate, with high strength, lightweight, high temp.
resistance, corrosion resistance, acid and alkali resistance, non-toxic,
tasteless, and other characteristics.
Equipped with a variety of safety devices to ensure the safety of operators,
simple operation, convenient maintenance.
Plate and filter press equipped with PLC control, automatic plate shifting,
automatic unloading, automatic drip tray, diaphragm pressing, open flow or dark
flow, washing/blowing mode, high temp. resistance of filter board, etc.

HongVadar relies on professional design, strict production management, the fine
processing procedure, provides high efficiency and energy-saving fully
automatic filter press for sale with prefercienal filter press machine price.
As the plate and frame filter press manufacturers and filter press machine
manufacturers/filter press plates manufacturers, HongVadar has passed the
international ISO9001 quality system certification, and with the design and
manufacturing capacity of pressure vessels. Customers can choose international
ISO, EU CE, and other standards for equipment design and production according
to their needs.

Technical Parameter (Hydraulic Chamber Filter Press)

Minimum Order: 1 sets
