Product Description
Electro Galvanized welded wire mesh is made of high-quality low-carbon steel
wire. It is formed by spot welding using automatic, precise and accurate
mechanical equipment. Its surface is flat, its structure is firm and even, and
its overall performance is good.Welded mesh is the most excellent anti-
corrosion resistance among all the steel wire mesh products, it is also the
most versatile wire mesh due to its wide application in different fields.

Assortments:
Electro galvanized before welded
Electro galvanized after welded

Welded Wire Mesh Application:
It is widely used in agricultural, industrial, transportation, horticultural
and food procuring sectors. It is also used in mines, gardening, machine
protection and other decorations.

Specifications:
Opening Wire Diameter Width Length
In inch In metric unit
1/4" x 1/4" 6.4 x 6.4mm BWG26-21 0.3m-2.0m 5m-50m
3/8" x 3/8" 10.6x 10.6mm BWG26-19
1/2" x 1/2" 12.7 x 12.7mm BWG25-16
5/8" x 5/8" 16x 16mm BWG25-16
3/4" x 3/4" 19.1 x 19.1mm BWG25-16
1" x 1/2" 25.4x 12.7mm BWG22-14
1" x 1" 25.4x 25.4mm BWG22-14
1-1/4" x 1-1/4" 30 x 30mm BWG20-12
1-1/2" x 1-1/2" 38 x 38mm BWG20-12
1" x 2" 25.4 x 50.8mm BWG19-12
2" x 2" 50.8 x 50.8mm BWG18-12
2” x 3" 50.8 x 76.2mm BWG16-12
2” x 4" 50.8 x 101.6mm BWG16-12
3” x 3" 76.2 x 76.2mm BWG16-12
3” x 4" 76.2 x 101.6mm BWG16-12
4” x 4" 101.6 x 101.6mm BWG16-12
4” x 6" 101.6 x 152.4mm BWG16-12
6” x 6" 152.4 x 152.4mm BWG16-12
6” x 8" 152.4 x 203.2mm BWG14-12
Other sizes can be customized according to your needs

Packing:waterproof paper inside and plastic film outside,pallet or other
packing way can be made according to your needs

We are one of iron wire manufacturers, barbed wire can be customized on demand,
hot-dip galvanized, electro-galvanized, etc., advanced galvanizing process.
galvanised wire has no welding slag, strong anti-corrosion ability and long
service life.

Our website:www.ykmetals.com

Minimum Order: 1 pieces
