ECONOMICAL PE FILM VERTICAL SIDE SEALING MACHINE

Economical PE film vertical side sealing machine has the function of automatic
film feeding, punching device, and manually adjusted film guiding system. The
final products to be sealed and cut are not limited by length.

PE FILM COMMERCIAL SHRINK WRAP MACHINE TECHNICAL PARAMETERS
Machine Model GNL-5545C（Edge Sealer）
Packaging Size L(no limit) X W330 X H150mm
Sealing knife Size ≤500mm
Packaging Speed 0-40 bpm
Power Supply 3Ф220V/380V    50/60Hz
Power 3KW
Max Current 10A
Air Pressure 5.5kg/cm3
Net Weight 300kg
Dimension L1650 X W900 X H1550mm

No. Name Qty Brand
1 PLC 1 OMRON, JAPAN
2 Touch Screen 1 MCGS
3 Circuit Breaker 10 SCHNEIDER, FRANCE
4 Temperature Controller 3 OMRON, JAPAN
5 Ac Contactor 2 SCHNEIDER，FRANCE
6 Material Induction Switch 2 BONNER, USA
7 Solid-state Relay 3 OMRON, JAPAN
8 Air Cylinder 1 SHAKO（TAIWAN, CHINA）
9 Cylinder Solenoid Valve 1 SHAKO（TAIWAN, CHINA）
10 Air Filter 1 SHAKO（ TAIWAN, CHINA ）
11 Proximity Switch 4 SICK, GERMAN
12 Conveyor Belt 3 SIGLIN,GERMEN
13 Power Switch 1 TIANYI,CHINA

As one of the leading packaging machine suppliers in China, We provide juice
pack machine, food packaging sealing machine, food package sealer, vertical
form fill seal machine and etc. For more information, please feel free to
contact us!

Minimum Order: 30 pieces
