Easy Maintenance Open View Bulldozer Equipped With Torque Converter

SD7NLGP bulldozer:Crawler bulldozer with semi-rigid suspension, hydraulic
transmission, high drive, and full hydraulic control; external power split
hydraulic torque converter, planetary power shift, single-lever control
gearbox. The modular design of the whole machine is the most prominent
structural feature, saving a lot of disassembly time. Pilot control, sensitive
response, high work efficiency, ergonomically designed operating system is
light, labor-saving and accurate. Multi-function instrument display, luxurious
interior, anti-rollover driver's cab that meets international standards have
distinctive characteristics of the times. Optional multiple working devices and
attachments.
Bulldozer Equipped With Torque Converter Performance Parameters
Engine WeiChai WP12G250E302
Operating weight 26800Kg
Ground pressure 54.2Kpa
Track gauge 2235mm
Gradient 30°/25°
Min. ground clearance 484mm
Dozing capacity 5.8m³
Blade width 4382mm
Max. Digging depth 635mm
Overall dimension 5425×4382×3482mm
