Double-Stage High Vacuum Transformer Oil Purifier

JUNSUN ZYD-150 Series Double Stage High Vacuum Transformer Oil Purifier
Machine is specially designed for treating transformer oil and other kinds of
insulating liquids in the oil-filled power equipment. Through degasification,
dehydration, and filtration process, the dissolved gases and moisture, solid
impurities, contaminations can be effectively removed from oil.

JUNSUN ZYD-150 Series Double Stage High Vacuum Transformer Oil Purifier
Machine is widely used in factory workshops, power station and power
transmission. Utilizing JUNSUN ZYD-150 High Vacuum Oil Purifier, the quality
of transformer oil will be greatly improved, thus extending the service life
of transformer oil and ensuring safety operation of oil-filled power
equipment.

Besides, with additional design, JUNSUN ZYD-150 Series Double Stage High
Vacuum Transformer Oil Purifier Machine can be also used as vacuum oil
drying/ vacuum oil filling/ vacuum pumping equipment for transformers.

MAIN FEATURES:
1. Double stage high vacuum pumping system: except the rotary vane vacuum
pump, this machine is also equipped with a root vacuum pump, so it has faster
vacuum-pumping speed and can reach a very good ultimate vacuum.

2. Equipped with JUNSUN specially designed and unique “Horizontal - Vertical
Combined Vacuum Tank”, together with advanced degasification and dehydration
technology, which can remove gas and water very quickly and effectively.

3. High precision three stage oil filtration system, including primary
filter, secondary filter, fine filter with gradually increasing precision,
the dimensions of filter element are bigger than most of other manufacturers,
which can effectively remove mechanical impurities from oil.

4. Equipped with automatic temperature control system, automatic oil level
control system, automatic defoaming control system, automatic pressure
protection system, which guarantees safe and reliable operation in the long
term.

5. Equipped with comprehensive protection mechanism, such as power
protection, pressure protection, motor overload protection. If any protection
mechanism is triggered, the machine will stop working automatically.

6. Equipped with high efficiency electric heating system, heating the oil
uniformly, avoid the deterioration of oil during heating process.

7. This machine can be operated both online and offline. In addition, it can
be used as an independent vacuum pump system for the evacuation operation of
the transformer (if you need this function, please inform us before
manufacturing).

Minimum Order: 1 sets
