Double Sided PCB

PCBA is a process requiring knowledge covering PCB manufacturing assembly, PCB
design, fabrication and a strong understanding of the final product. ZF is a
professional pcb manufacturing companies with high-quality, all of our products
have obtained ISO9001, ISO13485:2016, IATF16949:2016, IPC-A-610E, UL, RoHS
certifications.

The double layer pcb china(double-layer/double-sided printed circuit
board/breadboard) is more complicated than single sided PCB. The circuit
patterns, on both sides, are connected through a through-hole in the middle.
Various types of double-sided PCB are on the market, such as double sided
copper clad PCB, high Tg thick copper foil PCB, high-frequency PCB, and hybrid
dielectric base high-frequency double-sided PCB. Double-sided PCBs are widely
used in high-tech industries like telecommunications, power supply, computers,
industrial control, digital products, scientific and educational equipment,
medical equipment, automobiles, aerospace defense.

The production process of double sided PCB
Double-sided or 2 layer PCB is usually made of epoxy glass cloth copper-clad
laminates. It is mainly used for communication electronic equipment, advanced
instruments, and electronic computers with high-performance requirements.

The production process of two sided PCB can be generally divided into several
methods, such as process wire method, hole plugging method, masking method, and
pattern plating-etching method.

Advantages of double layer PCB
As one of the professional PCB fabrication companies in China, ZF Electronics
will introduce some features of double layer printed circuit board:
It makes it relatively easy to add conductive paths on the board, which means
you will have a PCB that better suits your needs.
As both sides are conductive, a large number of ICs and components can be
assembled at any time.
You can add more components as needed as there is an extra layer.
More space and flexible design allow the PCB to suit your requirements.
Dual layer PCB is ideal for demanding applications and advanced electronics.
If necessary, the size of the double-sided PCB can be reduced, because double
sides can be used.
This type of printed circuit board for sale may save you money because you
may only need one.
Double-sided PCBs can be used in many different applications and electronic
products, suitable for a wide range of industries.

The difference between double sided PCB and single sided PCB
Appearance: A single sided circuit board only has one layer, but the double-
sided PCB has 2 layers, with a via hole connecting double sided PCB circuit.
Different production processes: The 2 sided PCB has a copper sink process,
which is for the two-sided circuit conduction.

Parameters of 2 layer PCB board
Material: FR-4
Layers: 2L
Thickness: 1.6mm
Min.Hole Size: 0.3mm
Min.lineWidth: 0.127mm
Inner Layer Copper Thickness: 35μm
Outer Layer Copper Thickness: /
Surface Finish: OSP, HASL, HASL LF, Immersion Gold, ENIG
Min. Clearance of Hole to Line: 0.127mm

If you have questions about our double-sided PCB production capacity, double
sided PCB price, or the specifications required for your custom project are not
listed on this page, please feel free to contact us. We will reply within one
workday. Meanwhile, if you want to buy double sided PCB, we are also here to
provide quotation support and design support. Welcome to learn about our
production process.

As a professional double sided pcb manufacturer/2 layer pcb manufacturer, we
supply many high quality products by our own double sided pcb factory, if you
want to buy double sided pcb and know 2 layer pcb price/double sided pcb price,
please contact us.
