Double Bolt Clamps Double Bolt Hose Clamp

Double Bolt Clamps Double Bolt Hose Clamp Three Way Supplier

Double Bolt Clamps with plated iron two-bolt clamp and machine bolts and hex
nuts.

Product Description
Shijiazhuang Donghuan Malleable Iron Castings Co., Ltd. provide a variety of
high-quality double bolt clamps to meet all your needs. Double bolt clamps is a
sturdy iron-plated double bolt clamps with machine bolts and hexagon nuts. In
high temperature, abrasive material transportation and chemical fumes
environments, these clamps are used to secure hoses and provide a safe working
environment.

Double Bolt Clamp size list as below:
Name code size rang size Note Colour
22 Double Bolt Clamp DB SL-22 20-22mm Without saddles Yellow
29 Double Bolt Clamp DB SL-29 22-29mm
34 Double Bolt Clamp DB SL-34 29-34mm
40 Double Bolt Clamp DB SL-40 34-40mm
49 Double Bolt Clamp DB SL-49 40-49mm
60 Double Bolt Clamp DB SL-60 49-60mm Carbon steel saddles
76 Double Bolt Clamp DB SL-76 60-76mm
94 Double Bolt Clamp DB SL-94 76-94mm
115 Double Bolt Clamp DB SL-115 94-115mm
400 Double Bolt Clamp DB SL-400 90-100mm
525 Double Bolt Clamp DB SL-525 100-125mm Malleable iron saddles
White
550 Double Bolt Clamp DB SL-550 125-150mm
675 Double Bolt Clamp DB SL-675 150-175mm
769 Double Bolt Clamp DB SL-769 175-200mm
818 Double Bolt Clamp DB SL-818 200-225mm
988 Double Bolt Clamp DB SL-988 225-250mm
1125 Double Bolt Clamp DB SL-1125 250-300mm
1275 Double Bolt Clamp DB SL-1275 300-350mm

Double Bolt Clamp Features:
1. Inner surface has dual gripping ridges
2. Bolts lugs are reinforced to prevent bending out of alignment
3. Measure hose OD accurately before ordering clamps
4. Torque values for clamps are based on dry bolts. The use of lubricant on
bolts will adversely affect clamp performance

Installation instruction for double bolt clamp
Firstly, check the pipe end surface and assure that the pipe is smooth, then
aligning two piece of clamps and insert the bolt and connect them, finally hand
tighten nuts make sure oval next bolt completely fits into bolt hole. Please
make sure you use a wrench.

MILL TEST REPORT
SDH Double Bolt Clamp
Description Chemical Properties Physical Properties
Lot No. C Si Mn P S Tensile Strength
Elongation
ALL PALLET 2.76 1.65 0.55 LESS THAN 0.07 LESS THAN 0.15 300 Mpa
6%
Terms payments:
TT 30% prepayments of products before producing and TT the balance after
receiving copy of B/L, all price expressed in USD;
Packing detail:
Packed in cartons then on pallets;
Delivery date:
60days after receiving 30% prepayments and also confirming samples;
Quantity tolerance:
15%.

The main products are Malleable iron pipe fittings, tube clamps, Air hose
couplings, Camlock couplings, Carbon steel pipe nipples, Electric power
fittings, Steam couplings, Gas meter connectors etc.You can click here to learn
more.
