Diesel Underground Mining Dump Truck With 6 ton loading capacity

A 6 ton diesel underground mine dump truck is a type of truck, a truck with an
automatic dumping device at its loading position. Also known as dump truck. It
is composed of automobile chassis, hydraulic lifting mechanism, cargo
compartment and power take-off device.
There are two types of dump truck compartments: backward tipping and side
tipping. Piston rod movement is controlled by the control system. Backward
tipping is more common. Pushing the piston rod causes the truck to tip over,
and a few have two-way tipping.
Model: 6 Ton
Engine power: 70 KW
Axle model: Front axle 1069
Axle model: Back axle 1069
Dimensions of carriage: 2850*1600*500
Carriage thickness: Bottom 8 side 5
Tyre model: 700-16 mining tyre
Hydraulic cylinder model: 115*1000
Steering method: Hydraulic steering gear steering
Exhaust gas treatment: Water treatment
Driving style: Left-hand drive
Cab: Simple roof
Dimensions: 4600*1630*1500
Man-machine height: 1.9 m
Gear model: Gear shift
Load capacity: 6 Ton

Minimum Order: 1 sets
