Diamond + PDC Reaming Shell

Diamond + PDC Reaming Shell

Reamed shells are available for all types of core barrels and drill bits.
The product description
Reamed shells are available for all types of core barrels and drill bits. The
design is the result of years of experience. Reamed shells improve core
recovery and quality by reducing vibration and stabilizing coring. The longer
service life ensures that the aperture remains the same, preventing the new bit
from getting stuck in the narrow hole. The wash channel has been optimized to
keep the diamond cool enough without limiting flow, thus ensuring the lowest
circulating pressure. We are an Diamond Core Bits Exporter.

FEATURES&BENEFITS
* Maintains hole diameter longer to prevent new bits from sticking
* Improves core quality due to a stabilized core barrel.
* Unique design and diamond setting for long service life
* Flushing channels designed to ensure low circulation pressure

STANDARD SPECIFICATION
ITEM DIAMOND BIT REAMING SHELL
"Q"
Series
Wireline Size Bit-set OD Bit-set ID
mm inch mm inch mm inch
AQ 47.60 1.88 26.97 1.06 48.00 1.89
BQ 59.50 2.35 36.40 1.43 59.90 2.36
NQ 75.30 2.97 47.60 1.88 75.70 2.98
HQ 95.58 3.77 63.50 2.50 96.00 3.78
PQ 122.00 4.80 84.96 3.35 122.60 4.83
Swedish
Metric
T2
Series 36 36.0 1.417 22.0 0.866 36.3 1.429
46 46.0 1.811 32.0 1.260 46.3 1.823
56 56.0 2.205 42.0 1.654 56.3 2.217
66 66.0 2.598 52.0 2.047 66.3 2.610
76 76.0 2.992 62.0 2.441 76.3 3.004
86 86.0 3.386 72.0 2.835 86.3 3.398
101 101.0 3.976 84.0 3.307 101.3 3.988
Swedish
T
Series TAW 47.6 1.875 23.2 1.31 48.0 1.89
TBW 59.5 2.345 44.9 1.77 59.9 2.36
TNW 75.3 2.965 60.5 2.38 75.7 2.98
