Conduit body tee Conduit Bodies Three Way for sale

Conduit body tee Conduit Bodies Three Way for sale Conduit Unions

Product Description
1. Electric fittings
From 2012 our factory begin to produce the electric fittings, at first we
produce conduit body, including (LL,LR, LB,T) with malleable iron, then enlarge
the other items. Now we can produce the Guat, bushing, EYS, Lt connector with
lugs, lt connector without lugs, union, enlarger, close nipple, drain breather,
cover, aluminum lugs etc. In the beginning we use the black sand mould to
produce, then we improve step by step, now we all revised the new mould with
yellow sand, the thread is maked by CNC machine. The surface we mainly make now
is electric, but also can make with hot-dip galvanized firstly then electric.
Also for the new item we also have the experienced to open the mould, if you
are interested welcome to contact with us.
2. Usage:
Conduit bodies are used to gain access to the interior of a raceway for wire
pulling, inspection and maintenance where the raceway changes direction. Allows
connection of straight conduit runs, branch conduit runs and 90° bends. The
union used for joining conduits, or conduit to enclosures or other devices,
without rotation of conduits, etc. Allows future access and removal of system
components.
3. Types: Conduit fittings
Produce name SIZE PACKAGE
LL 3/4,1,1-1/2,2 In small box then in big carton
LR 3/4,1,1-1/2,2 In small box then in big carton
LB 3/4,1,1-1/2,2 In small box then in big carton
T 3/4,1,1-1/2,2 In small box then in big carton
GUAT 1/2,3/4,1, In small box then in big carton
BUSHING 3/4,1,1-1/4,1-1/2,2,2-1/2,3,4 In small box then in big carton
UNION 3/4,1,1-1/2,2 In small box then in big carton
COVER 3/4,1,1-1/2,2 In small box then in big carton
LT CONNECTOR 3/4,1,1-1/4 In small box then in big carton
4. Material:
Bodies---Malleable iron with electrogalvanized
Gaskets---Neoprene
Cover-- , -Malleable iron or carbon steel
Cover Screws---Stainless steel
5. Size: 3/4''-2''
6. Thread: NPT
7. Terms payments: TT 30% prepayments of products before producing and TT the
balance after receiving copy of B/L, all price expressed in USD;
8. Packing detail: Packed in cartons then on pallets;
9. Delivery date: 60days after receiving 30% prepayments and also confirming
samples;
10. Quantity tolerance: 15% .

Shijiazhuang Donghuan Malleable Iron Castings Co.,ltd supplies Malleable iron
fittings, Ductile iron fittings, Gray iron fittings and other steel products,
with a long history and unchanging faith in producing high-quality products.
