COIN612/R

WLP+ASIC Uncooled thermal camera module

COIN series uncooled thermal imaging camera core integrates the wafer-level
package detector produced by GST, ASIC chip for imaging processing, micro-
motion electromagnetic threshold shutter and general optical interface. It is
beneficial to OEM customers for secondary development and suitable for the
development and integration of thermal imager in various applications.

640x512IR resolution

12μmPixel Pitch

＜3s Start-up Time

＜40mKNETD
COIN612 integrates 640x512@12μm wafer level package (WLP) infrared thermal
detector, high performance signal processing circuit and image processing
algorithm.

The COIN612 infrared thermal camera core features in sharp and crisp image
presentation, compact size and low cost. It also has an optional thermographic
function with measurement range from -20℃~550 ℃ for industrial temperature
measurement.

Its lightweight and flexible features with various industry standard interfaces
make it beneficial to OEM customers for secondary development and integration
in all kinds of infrared thermal cameras.

Until now, we have provided our customers with various mature and stable
infrared thermal imaging solutions. It’s easier for COIN series to be
integrated into more terminal products and greatly reduces the cost for
customers.

Technical Parameters
Model
COIN612/R
ADD TO COMPARE

IR Detector Performance
Resolution 640X512@12μm
Spectral response 8~14μm
NETD ＜40mk

Image Processing
Frame rate 9Hz/25Hz/30Hz/50Hz/60Hz
Start-up time ＜3秒
Analog video PAL/NTSC
Digital video Y16/YUV/BT656
Dimming Linear/Histogram/Mixed three modes
Digital zoom 1~8X continual zoom，step size 1/8
Image display Black hot/White hot/Pseudo color
Image direction Horizontally/Vertically/Diagonally Flip
Image algorithm NUC，AGC，IDE，DNR

Image Display Performance
Communication mode RS232-TTL, 115200bps
Supply voltage 3.5~5.5V
Typical power consumpti <0.75W

External Cable Connection
Standard external interface 50pin_HRS interface
Operating temperature range -10℃~50℃
Temperature range -20℃~150℃，100℃~550℃
Temperature accuracy ±3℃ or ±3%
Sdk ARM/Windows SDK，full screen thermograph

Physical Characteristic
Dimension(mm) 25.4x25.4x14.1（Including shutter）
Weight 机芯：13g±0.5g（Including shutter）
Operation temperature -40°C~+70°C
Storage temperature -45°C~+85°C
Humidity 5%~95%，non-condensing
Vibration Random Vibration 5.35grms，3 axis
Shock Half-sine wave，40g/11ms，3 axis 6 directi

Optics
Optional lens Fixed focus athermal：8.8mm/13mm/19mm
* All specifications are subject to the actual product. Guide sensmart
reserves the right to change the technical specifications without notice or
liability to you.


For more information about guide infrared china, please feel free to contact
us!

Minimum Order: 50000 sets
