Chromium Mist Dust Removal

Product Introduction：
Chromium Mist Dust Removal for Rotogravure cylinder making machinery Chromic
acid density are high and easy cohesion.First retrieve chromium acid.Chrome
dust for gravure chrome plating machine the rest pollutants of waste-air enter
into the subsequent mist purifier. After treated by the physical and chemical
absorption,the pollutants will be absorbed in the wash solution to achieve
removing the substance of contamination


Product Advantage
1,Chromic acid is an expensive reagent, and the recycling of chromic acid is
very valuable.Chromic acid density is larger and easy to condense, chromium
acid fog collection, under the action of induced fan, into the recovery device,
Chrome dust for gravure chrome Electroplating tank device set multi-layer
interception filter, through the filter interception effect, make the chromium
acid fog condensation into liquid, liquid chromium acid along the filter into
the lower recovery container, lower recycling container set recovery pipe, when
the recovery liquid reaches a certain amount, discharge chromium liquid in the
recovery device.
2,Spray tower for absorption of acid mist Working principle: The porous sieve
plate exhaust gas scrubbing tower is adopted. Engravure printing cylinder
Chrome dust for Electroplating gravure cylinder the scrubbing solution will be
evenly sprayed to the surface of fillers through nozzles to keep the surface
wet when the exhaust gas flows through the filling layer in scrubbing tower,
meanwhile, the exhaust gas will contact with the scrubbing solution on fully
wetted filling layer, and by utilizing the physical and chemical effects, the
pollutants in exhaust gas will be absorbed by the scrubbing solution, thus to
realize the purpose of pollutants removal; then, the water saturated gas will
be treated in demister to remove extra moisture. The clean gas after being
scrubbed in scrubber and dried can meet certain standards, and can be
discharged into the atmosphere.

Minimum Order: 1 sets
