The cement bulk loader machine is a special equipment for bulk cement. It
connects the cement silo with the cement bulk transportation and realizes the
automatic or semi-automatic delivery of bulk cement through a series of
interlocking actions of control devices. According to the discharge method, it
can be divide dry powder bulk machine and warehouse side bulk machine.

Product Description
Dry ash bulk material is completely isolated from the traction mechanism.The
whole working process is in a closed state, which can effectively prevent dust
from escaping.DRY ASH BULK MACHINE is mainly used in the bulk of power plant
fly ash and cement plant cement bulk.
This product is applied to the loading of corrosion-resistance bulk materials
for industry fields such as electric power, constructing metallurgical coal and
chemistry etc. In power plant it is mainly applied to the loading for truck and
ship under hopper or ash silo. It can realize the auto loading through
operating with the feeder facilities under silo by logic control. It has a good
loading efficiency and sealing performance with no dust pollution. It is the
best solution for track loading ship loading.

Technical Parameters of cement bulk loader machine
1. The telescopic distance of the loading head is 1600mm, and the extension and
deceleration speed is 8m / min;
2. Hoisting speed of hoist machine 8m / min; Power 05.KWJ; Voltage 380V;
3. Technical parameters of the pressure controller in the material level
indicating mechanism: operating pressure 250-5000Pa; Rated voltage 220V; Rated
current 3A, applicable medium: clean gas; pressure 0.01MPa, fan technical
parameter pressure 220V, power 350V;
4. The dust collector is self-provided, the dust collection air volume is 40m3
/ min
Model SZJ60 SZJ100 SZJ200
Loading capacity (t/h) 60 100 200
Feeding tube diameter(mm) 300
Vacuum tube diameter(mm) 108
Bulk head distance(mm) 1500-2500
Lifting speed(m/min) 3.3/6.6

warehouse side bulk machine Structural features
Cement bulk load machine is including electric control box, electric motor,
speed reducer, pulley group expansion tube, dust suction tube, steel wire rope
and so on. They are connected together by wire ropes and suction pipes to form
a retractable structure.
The dry ash bulk machine can be interlocked with the feeding equipment under
the silo. After the tank truck is full, it will automatically stop the loading
to realize the automation process. The loading efficiency is high and the low
dust pollution. It is ideal for loading bulk cement for truck and ship.

Maintenance of dry powder bulk machine
The operator of the dry powder bulk machine should conduct a comprehensive
inspection of the equipment 5-10 minutes before starting the machine, refuel
and clean it according to the regulations, and then put it into use after the
test is correct.
Strictly abide by the operating regulations and pay attention to the operation
of the equipment at any time. If abnormalities or faults are found, the machine
should be immediately shut down for inspection and eliminated in a timely
manner. Failures that cannot be eliminated should be notified to the
maintenance personnel for overhaul, and the maintenance personnel should make
maintenance records.
Do the cleaning, wiping, lubrication, and inspection of the bulk cement machine
within 10-15 minutes after work, and make records.

Founded in 2007, Hebei Taizhe Machinery Equipment Trading Co., Ltd is a dust
collection system manufacturer with R & D, design, production, installation and
after-sale service. Have many years of export experience, worthy of your trust!
