Checkered Steel Plate

Checkered Steel Plate
Description
Checkered Steel Plate is a steel plate with a raised (or recessed) pattern on
the surface. The pattern is lentil-shaped, diamond-shaped, round bean-shaped,
and mixed flat and round shapes. The lentil shape is the most common in the
market. The pattern can be a single diamond, lentil or round bean shape, or a
combination of two or more patterns to become a combined pattern plate.
Due to the diamond pattern, the risk of slipping is greatly reduced. Checkered
Steel Plate is commonly used in structures such as stairs, ramps, walkways and
vehicle interiors. It can also be found in construction applications.
Checkered Steel Plate Precautions
1. After the materials are transported to the site, they should be stacked
according to the specifications and installation positions, and the square wood
should be padded to prevent the rain from scouring. The stacking height should
not be too high to prevent deformation caused by being overweight.
2. In order to meet the requirements of the overall construction progress, the
laying of the patterned steel plate is closely connected with the installation
of the steel structure. After a certain stage of anti-corrosion work on the
steel beam, the patterned steel plate can be laid. The laying sequence is the
same as the steel beam installation sequence.
3. On the patterned steel plate, the lifting lugs are welded on the ground, and
the holes to be welded on the secondary beam and the frame beam are cut with
flame. The size of the opening is 6mmx12mm, and the spacing is not more than
0.5m.
