Card Edge Connectors

Card edge connectors are one of the original devices used to provide an easy,
high-speed transmission of data and communication. These edge card connectors
provide low resistance, robust interconnect solutions at a low price. Card edge
connectors are available in an extensive array of configurations that can be
tailored to countless applications. Find the pcb card edge connector you are
looking for today at Greenconn!

Types of Card Edge Connectors
PCI
PCI, also known as Peripheral Component Interconnect, is a local computer bus used
for the purpose of successfully attaching hardware components. These connectors
are typically used to allow add-on network, sound or video cards, modems and other
peripherals to be attached to a computer motherboard.

CLB202

CLB203

CS , CC215

What is an Edge Connector?
A high speed edge card socket is a female connector that, in order to transmit
data, permits an outside card to be inserted. These card edge connectors provide
durable and robust solutions that allow for cards to be frequently inserted and
extracted. Since card edge connectors are only one-sided solutions, they come at a
low cost yet still provide easy, high-speed transmission. These edge connectors
are commonly used in personal computers but are also applicable for their
implementation in energy applications, traffic control systems, transportation
systems and medical equipments.

Card Edge Connector PCB Design
Card edge connectors are designed with a female connector attached to a PCB. A
mating card is then inserted into the card edge connector (female) in order to
allow for the transmission of data or communication. The connector provides a
tight fit on the card which causes for an optimal interconnect. Card edge
connectors can also be designed with polarizing keys to ensure that the mating
card can only be inserted correctly into the connector in one way. At Greenconn,
our card edge connectors are designed with various configurations that can
accommodate any application.

How to make a PCB Edge Connector?
Card edge connectors are made with either one or two rows of contacts. These
contacts are made of metal and availible in various kinds of metal plating. Each
metal offers its own set of advantages regarding rust and corrosion resistance. We
offer plating solutions which include: gold, copper, tin and nickel. These
contacts are typically found within a housing that can be provided in various
types of plastic housing. Greenconn's card edge connectors are offered in straight
and right angle variations. For further inquiries, contact a sales representative
today!
