CAN Bus Display SPD-043-Ax

CAN Bus Display SPD-043-Ax
Product Description
The SPD-043-Ax series is a 4.3’ CAN Bus display developed by SonnePower. It
is a display screen based on Codesys 3.5 programming. The product features a
screen resolution of 480*272, a contrast ratio of 450, and a brightness equal
to or greater than 400cd/m2. It has 2 CAN bus interfaces, 1 RS232 serial port
for communication, 8 IO resources, and high port multiplexing.
In addition, this Mobile machinery display has the advantages of compact size,
high integration, and fast response speed. It can operate in harsh environments
such as wide temperature ranges, high humidity, strong vibrations, and impacts.
It is widely used in various fields, including engineering machinery,
sanitation equipment, mobile devices, and heavy-duty equipment.
32-bit high-performance MCU
480 * 272 resolution, 450 contrast, ≥ 400cd/m2 brightness
8 channels IO resources with high port reuse rate
2 channels CAN, supporting Codesys3.5 programming
1 standard RS232 communication port, Baud configurable
All input ports support incorrect power and ground connections
All output ports are equipped with short circuit and overheat protection
Protection level: IP65
