Butyl Rubber

Butyl rubber is a synthetic elastomer made by combining isobutylene and
isoprene. It is a white or off-white translucent elastomer with a density of
0.91~0.92g/cm. Butyl rubber has poor molecular chain flexibility and compact
structure, and its air tightness is the first among rubbers. Synthetic butyl
rubber has excellent heat resistance, weather resistance, ozone aging
resistance and chemical corrosion resistance. Properly formulated butyl
vulcanizate can be used for a long time at 150~170C, and the heat resistance
limit can reach 200C. Butyl rubber products exposed to sunlight for a long
time. And in the air, its performance changes very little, especially the anti-
ozone aging performance is 10-20 times better than natural rubber. Butyl rubber
has excellent resistance to acids, alkalis and redox solutions except for
strong oxidizing concentrated acids, and it swells very little in polar
solvents such as alcohols, ketones and esters. The above characteristics are
determined by the extremely low degree of unsaturation, strong structural
stability and non-polarity of butyl rubber.

There are many applications for butyl rubber, but this synthetic rubber is
popular for some key products. Tire inner tubes, speakers, roofing, and gas
masks are often made with butyl. Butyl is also used by the pharmaceutical and
sporting industries.

Types of Butyl Rubber
Regular Butyl Rubber
Regular Butyl Rubber has superior air impermeability, outstanding performance
of heat-resistance, chemical corrosion-resistance, thermal aging resistance,
and good curing performance. it has high tensile strength and elongation at
break, which is determined by the crystallinity of butyl rubber in the
stretched state. This means that butyl vulcanizate has better strength even
without carbon black reinforcement, so it can be used to make light-colored
products.

Brominated Butyl Rubber
The chain molecules of butyl rubber are partially introduced with bromine and
denatured. Vulcanization is fast, can be mixed with NR, SBR, etc., and has good
adhesion to metals or other polymers.

Chlorinated Butyl Rubber
After chlorine is introduced, the vulcanization is rapid, and the compatibility
with other rubbers is good The heat resistance of chlorinated butyl rubber is
excellent. The ozone resistance and other characteristics comparable to those
of Regular butyl Rubber is also good.

Advantages of Butyl Rubber
Butyl rubber is a common elastomer that has been in commercial use since the
1940s. The ability for butyl to retain air and its flex properties made it
ideal for tire inner tubes as its first major application.

Butyl rubber is heavily resistant to gas and moisture permeation. It is also
resistant to oxygenated solvents, alkalis, flexing, and abrasion, making it
favorable for certain applications. Butyl rubbers can provide high energy
absorption and electrical isolation performance as well.

Butyl rubber is also highly resistant to sunlight, ozone, heat aging, animal
and vegetable oils, ammonia, and countless other chemicals. The molecular
structure of butyl can even be oriented to resist stress.

What Is Butyl Rubber Used For?
Based on that Butyl rubber has poor molecular chain flexibility and compact
structure, and its excellent air tightness butyl rubber is an important
material in the manufacturing of tubeless tires, inner tubes, sports-ball
bladders, glove-box gloves, etc.

As a waterproofing material, it is applied as a liner in tanks and ponds. It is
used as a patching material for membrane roofs and as a sealant for insulated
windows.

As a vibration dampener, butyl rubber is used for shock mounts, suspension
bushings, and car- and truck-body mounts. Speaker cone edges are often made
from butyl rubber today where once they were commonly made of foam. Stoppers
for labware and medical equipment are manufactured from the material. Owing to
its low permeability, it is also used in making gas masks. Butyl rubber is
flexible enough that it can achieve a good face seal.

Butyl synthetic rubber, in its food-grade form, is used to make chewing gum. It
has all but replaced the gum of the Chicle tree except in a few specialty,
natural products. There have been some efforts to collect used chewing gum and
recycle it into new products. Improper disposal of chewing gum is a chronic
urban blight.

As one of butyl rubber suppliers, we can offer sorts of related products for
sale, and the butyl rubber price is low, anything you need, please leave us a
message.

As a rubber raw material manufacturer, we will do our best to meet all the
needs of customers.

Minimum Order: 100 kilograms
