BRAKE SHOE WELDER

The brake shoe welding machine is independently developed and produced by Xihe.
At present, the medium frequency roll welding machine is used for single rib
brake shoes, and the gas shielded welding machine is used for plug welding,
fillet welding and reshaping of double rib brake shoes of heavy trucks. The
equipment adopts the color touch screen to control the parameters. The
clamping, positioning, displacement, welding and unloading of the workpiece are
automatically completed. The optimized program design makes the connection of
each step smoother and the welding efficiency higher.

HOW DOES BRAKE SHOE WELDER WORK?
The equipment is manually loaded, then the mold is clamped, and the product is
welded by medium frequency welding or gas shielded welding. Rotate the fixture
to complete all welding points, and finally unload automatically. Complete the
whole process.

How Does Brake Shoe Welder Work?
TECHNICAL REQUIREMENTS OF BRAKE SHOE WELDER
1
Brake shoe is an important component in vehicle braking system. Therefore, it
is necessary to ensure that the welding shoe of the brake shoe should not
overflow during welding, thereby reducing subsequent grinding. The penetration
depth and strength of each solder joint should be ensured.

2
The solder joints should be uniform and free of defects such as undercut,
cracks, and lack of fusion. You may need to configure multiple welders to
ensure consistent welding. It is also important to keep the output welding
voltage consistent with this setup.

FEATURES OF BRAKE SHOE WELDER
brake shoe welder
FIRST
Nice weld
The workpiece is clamped by hydraulic pressure, which can ensure the welding
quality. The equipment is equipped with a brand gas shielded welding machine,
and the welding shape is beautiful.

brake shoe welder
SECOND
Easy to operate
The control system adopts PLC and color touch screen, which is convenient for
operation. The rotation of the workpiece is driven by a servo motor, and the
positioning is accurate and reliable. Humanized design of equipment. Easy to
understand, easy to learn, easy to operate.

As one of the most professional laser welding machine suppliers, we provide
welding machine laser, stainless steel welding machine, metal lathe and milling
machine, welding machine laser, etc. For more, contact us.

Minimum Order: 1 sets
