BEST Quality High Performance Current & Voltage Transformer CT PT Analyzer

JSCP-405 Series High Performance CT PT Comprehensive Analyzer is used to
measure all kinds of current transformer and voltage transformer. It can
calculate the ratio errors and phase angle errors of current transformer and
voltage transformer at rated burden and working burden in one-time test. The
tester can automatically evaluate the test results according to the selected
standard to determine whether the transformer is qualified.

TESTS FOR CURRENT TRANSFORMER
1. Excitation curve and parameters test
2. Turns ratio test
3. Ratio and phase error test
4. Polarity mark check
5. Winding resistance measurement
6. Secondary loop burden measurement
7. Error line curve test for protection CT
8. Transient CT parameters test
9. CT nameplate guess
10. Saturation hysteresis loop curve measurement

TESTS FOR VOLTAGE TRANSFORMER
1. Turns ratio test
2. Ratio error and phase angle error test
3. Polarity test
4. Secondary burden test
5. Winding resistance test

Minimum Order: 1 sets

BEST Quality High Performance Current & Voltage Transformer CT PT Analyzer
