Beer Fermentation Storage Tank

Beer Fermentation Storage Tank
Feature Description:
The Beer Fermentation tanks make by ZYBREW use top class stainless steel, can
be SUS304, 304L or 316L, surface treatment can be 2B or precise polish or
mirror polished.
All fittings installed with tanks using top brand in China or brand from
Germany or other countries.
The inside surface treatment is more important for us, it is priority to make
sure the inside surface is under guarantee of qualified beer.
Capacity range: 5HL-300HL or 5BBL-300BBL
Details of Beer Storage tank:
Domed top and cone bottom cone, cone angle: 60-90 degree
With 25% head space for fermenation
 Wall thickness: 3-4mm, depending on tank size
Pressure: 2-3 bar / 15-30PSI
Dimple plate cooling jacket, cylinder and bottom cooled, Polyurethane
insulation
Four adjustable legs, with leg bolts
Diaphragm pressure gauge with CIP arm
Top: with CIP arm, breathe valve, optional dry hopping port
Cylinder: Glycol inlet / oulet, side manway, PT100 / 200, sample valve, level
tube (optional)

Click to Enlarge
