Bao-1000 Welding Fume Extraction Systems

Bao-1000 welding fume extraction system are used to purify the fume generated
during welding of metal materials. Bao-1000 is equipped with a high-power fan
with high suction and low operating noise. It has a four-stage high-capacity
filter to ensure high-efficiency purification of dust, odor and harmful gases.
The filtration efficiency of bao-1000 can reach 99.7%, which can filter 0.3
micron micro dust (Laboratory) and meet the indoor emission standard.

Advantage Of Bao-1000 Welding Extraction System
It can filter 0.3 micron dust.
Imported motor, stable performance, low noise, can work continuously for 24
hours.
The suction arm hose is made of high-grade polyester, which is fireproof and
flame retardant.

Specification Of Bao-1000 Welding Fume Extraction Systems
Air Flow 1000m3/h
Voltage / Frequency 220V, 50Hz
Input Power 750W
Air Pressure 2000Pa
Filtration Rate 99.97%
Filter Type G3 primary Filter + F5 medium efficiency filter+ H13 HEPA
filter + gas filter
Noise ≤ 60dB
Exhaust Arm φ150mm x 1.8M
Machine Dimension 550*550*1450mm
N.W 100kg

Application Of Bao-1000 Welding Fume Extraction Systems
Suitable for single station manual arc welding, argon arc welding, secondary
welding, grinding and polishing and other fume collection and filtration.

Xintchillers is a reliable industrial water chiller manufacturers, we provide
industrial water chiller, fume extractor and etc. Want to know more Please
contact us now.

Minimum Order: 500 sets
