Automation Pellet Mill Machine Remote Control Pellet Making Machine 1-3ton

Product Description
Automation Remote Control Centrifugal Vertical Ring Die Pellet Mill Machine
1-3ton/H Product Description:
The circular model biomass granulator is a machine widely used in the field
of biomass energy. Its main function is to convert biomass waste into
granular fuel, so as to make full use of heat energy, power and fuel.


This paper will introduce the characteristics, applications, advantages and
other contents of the ring model biomass granulator from the following
aspects.

I. Characteristics

1. High efficiency: The compression technology adopted by the circular model
biomass granulator can quickly convert raw materials into high-quality
granular fuel with high production efficiency.

2. Energy-saving: The circular model biomass granulator is driven by a
motor, which can realize an energy-saving and environment-friendly
production mode.

3. Reliability: the materials and manufacturing of the ring model biomass
granulator, its stability and reliability.

4. Simple operation: The circular-mold biomass granulator adopts intelligent
control system, which is simple to operate and easy to maintain.

Second, the application

1. Biomass fuel: The circular model biomass granulator can convert biomass
waste into high-quality granular fuel, which is widely used in the field of
biomass energy.

2. Power and heat energy: The granular fuel produced by the circular model
biomass granulator can be used in power generation, heating and other
fields, which provides important energy support for people's production and
life.

3. Eco-environmental protection: The application of the circular model
biomass granulator can effectively reduce the discharge of biomass waste,
reduce environmental pollution, and contribute to the cause of eco-
environmental protection.

Third, advantages

1. Economic benefits: The production cost of the circular-mold biomass
granulator is low, which can create rich economic benefits for enterprises
or individuals.

2. Environmental protection benefits: The circular model biomass granulator
can realize pollution-free production process, which has significant
benefits for environmental protection.

3. Social benefit: The wide application of the circular model biomass
granulator is helpful to promote the development of biomass energy and
contribute to social and economic development.

Fourth, the development trend

With the continuous improvement of environmental awareness and the rapid
development of biomass energy field, the application prospect of ring-shaped
biomass granulator will gradually expand.

In the future, the biomass granulator will become more and more intelligent
and automatic, and the production efficiency and environmental protection
benefits will be further improved, making greater contributions to the
construction of ecological civilization and sustainable economic
development.



In a word, the circular model biomass granulator is an efficient, reliable
and environment-friendly machine with wide application prospects, and its
application can make important contributions to the development of biomass
energy field and the sustainable development of social economy.

Features:
1. The mold is vertical and vertical feeding; the mold is stationary, the
pressure roller rotates; the material is centrifuged, the material
distribution is uniform;
2. 360 degree output high efficiency and energy saving; automatic
lubrication system high pressure filtration, clean and smooth; independent
frequency conversion, to ensure pellet molding.
3. The pelletized fuel after molding has a large specific gravity, is small
in volume and resistant to combustion, and is convenient for storage and
transportation. The volume after molding is 1/30 of the volume of the raw
material, the specific gravity is 10-15 times of the raw material, and the
calorific value can reach 3400-6000 kcal.
4. Material and Finished Production: wood machine pellet is suitable for all
kinds of crop straw, wood chips, bamboo chips, rice husks, branches, bark,
peanut melon shell, bagasse, Chinese medicine residue, sage and other raw
materials, water content 10-30 % can be processed.
​

Technical Parameters:
Model
HY-450
HY-560
HY-600 ,
HY-700
Power
55+3+1.5+1.5+0.37kw
90+3 , +1.5+1.5+0.37kw
110+3+1.5+1.5+0.37kw
132+3+1 , .5+1.5+0.37kw
Inner Dia of ring die
450mm
550mm
600mm
700mm
Capacit , y
800-1000kg/h
1500-2000kg/h
2000-2500kg/ , h
2500-3000kg/h
Dimension
2200*1100*2000m , m
2350*1300*2300mm
2600*1300*2400mm
2900* , 1300*2400mm
Weight
4.7t
5.8t
6.9t
9 , t
Diameter of Pellets (MM):6-12mm
Temperature of Pellets (°C):80-100
Moisture of Feed Materials (%):15-20

Applications:
1. Wood waste, scobs, branch, palm tree, sugarcane residue, sawdust, medical
slag, hay, discarded edible fungus.
2. Bean stalk, wheat stalk, corn stalk, cotton stalks, sunflower stalks,
mustard stalk, rice stalks, coffee husk, cotton shell, peanut shell, rice
shell, coconut shell.
3. Livestock and poultry's waste, tea waste, tea waste, forestry wastes,
forestry wastes, wood chips and many other organic waste resources.
Support and Services:
Pellet Mill Machine Technical Support and Service:

Provide technical assistance to customers regarding care and maintenance of
Pellet Mill Machine.
Provide troubleshooting advice and assistance to customers having difficulty
operating the Pellet Mill Machine.
Provide replacement parts for Pellet Mill Machine.
Provide training on Pellet Mill Machine operation and maintenance.
Provide installation and commissioning services for Pellet Mill Machine.
Provide technical consultation on Pellet Mill Machine.
FAQ:
Q: What is the brand name of the Pellet Mill Machine?
A: The brand name of the Pellet Mill Machine is ZHONGDEBAO.
Q: What is the model number of the Pellet Mill Machine?
A: The model number of the Pellet Mill Machine is EWVR.
Q: Where is the Pellet Mill Machine from?
A: The Pellet Mill Machine is from China Henan.
Q: What certifications does the Pellet Mill Machine have?
A: The Pellet Mill Machine has CE,SGS,BV certifications.
Q: What is the minimum order quantity of the Pellet Mill Machine?
A: The minimum order quantity of the Pellet Mill Machine is 1 set.
