Automatically Slag Discharging With Operating CCS RMS Separator For HFO Mar

Automatically Slag Discharging With Operating System With CCS And RMS
Certificated Separator For HFO Marine


Company Information

We are one of the world's leading manufacturers of disc centrifuges, decanters,
separation systems for land power station and container typer power plant. We
focus on the necessary equipments on the power station, environmental
protection, energy recycling, chemistry and etc. Now, there are over 150series
of decanter centrifuges and disc separators used home and abroad.

Technical parameter:

Fuel Oil Separator is mainly used to remove water and mechanical impurities(cat
fines) from diesel oil, lubricating oil, heavy fuel oil(HFO) and other mineral
oil in marine diesel engine unit and land-used diesel generator unit of power
station so as to reduce wear of the diesel engine and other machine, and
prolong engine life.

The model is also used to separate two unsolvable liquids with different
specific gravity or remove small amount of solid particle from liquid.


We have the following advantages:



1. After separation,it could reach that the maximum water content in the output
is 0.3%, and the maximum solid particle is 0.03%.This is also the CCS
standard.And we could provide CCS certificates and RMS certificates to prove
their function and usage.



2. We could make the HFO to 720CST,the separation effect feedback is very good



3. We are the first and largest company handling industrial oils in the
country, and we have been involved in setting standards for the shipyard
industry



4. The oil we handle is above national standards,all Marine diesel engines on
Chinese ships are supplied by us



5. Our separator can be adjusted by no specific gravity ring or specific
gravity ring adjustment, automatically calculating the slag discharge time and
equipped with Intelligent operating system for operating easily.



And more...


Automatically Slag Discharging With Operating CCS RMS Separator For HFO Marine
0
Discharging type Manual discharging
Max capacity L/h 14000(0# diesel oil)
Motor power Kw 11-15
N.W. kg 730
Volume of the slag cavity L 2
Discharge type Variable discharge
Type of output Centripetal pump
Installation dimension L × W × H (mm) 1200x810x1225
