ASTM A182 F304 Gate Valve

Buy our Stainless Steel F304 Forged Gate Valve, designed as per API 602 standards
with a 3/4 inch size, and 800 LB capacity. The valve features a sturdy A182 F304
body, Trim 20, and Handwheel for easy operation. Suitable for SW applications.

Valve Description:
1851006 API 602 Forged Gate Valve 0.75G8SF30420
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 3/4 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A182 F304
Trim Material: SS304+STL, No.28
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing
Gland

Minimum Order: 1 sets

ASTM A182 F304 Gate Valve
