AAK Solenoid Cartridge Valve Equivalent to HydraForce SV08-40

This week, we’d like to introduce a Hydraulic Screw-in Solenoid Cartridge
Valve equivalent to HydraForce standard part SV08-40.

It is a solenoid-operated, 4 way, 2 position, direct-acting spool type,
screw in hydraulic cartridge valve.

The features of this cartridge valve:
Continuous-duty rated coil.
Hardened precision spool and cage for long life.
Optional coil voltages and terminations.
Efficient wet-armature construction.
Cartridges are voltage interchangeable.
All ports may be fully pressurized.
Unitized, molded coil design.
Manual override option.
Optional waterproof E‑Coils rated up to IP69K.
Compact size.

A customer in Brazil placed a test order for 10 pcs last September, in 2022.
After 12 months of testing, it proves that the function and performance of
AAK hydraulic solenoid cartridge valve E-SV08-40 benchmarked the quality of
HydraForce SV08-40. Today, we received their re-peat order for 500 pcs qty.

AAK hydraulic screw-in solenoid cartridge valve 2 advantages:
1. Function and Performance benchmarking HydraForce
2. Its service life is 2 times that of its domestic peers

Technical parameters of AAK E-SV08-40 Hydraulic Screw-in Solenoid Cartridge
Valve:
Max. Operating Pressure: 207 bar (3000 psi)
Flow: 11.4 L
Internal Leakage: ＜82ml/min at 207 bar (3000 psi)
Temperature: - 30 to +100 °C (with Standard Buna N seals)
Cavity: 08-4
Fluids: Mineral based or synthetic hydraulic fluid with lubricating
properties
Fluid Viscosity Range: 7.4 to 420 cSt

Till now, AAK E-SV08-40 hydraulic screw-in solenoid cartridge valve has been
purchased by foreign customers from Russia, Brazil, Turkey and USA. You are
welcome to try it out.

AAK HYDRAULIC VALVES (734) 2023-12-11

https://www.aakindustry.com/info , -detail/solenoid-cartridge-valves-aak734

Click to Enlarge
