AAK Hydraulic Pressure Control Valve Reduce Energy Consumption by 20%

Els is from South Africa, and operates hydraulic machinery business very well
in the local market. Recently, she wanted to reduce the energy consumption of a
high-pressure hydraulic power unit. The hydraulic pressure control valve in the
original system, coupled with multiple changes in fluid direction, results in a
small fluid path, resulting in significant energy loss and high energy
consumption in the system. The original hydraulic pressure control valve
manufacturer advised that the 350 bar high pressure is the root cause of high
energy consumption and the valve is the standard part of HydraForce hydraulic
pressure control valve. The manufacturer is not willing to change the program.
Els was very helpless.

Els found AAK hydraulic valves via Google search. She left a message on AAK
website: Are you willing to improve the standard part of HydraForce hydraulic
pressure control valve to meet the energy consumption needs of our equipment?
Upon seeing this message, it is probably clear that other hydraulic cartridge
valve manufacturers in China are unwilling or unable to optimize the standard
part of HydraForce hydraulic pressure control valves. According to the
hydraulic system and working conditions of the equipment she provided, the
standard part of the HydraForce hydraulic pressure control valve is indeed not
suitable for their equipment. If the original 90 ° guide flow is optimized to
180 ° direct flow, and the optimization is successful, the energy consumption
can be reduced by at least 15%. Els paid a development fee of $2,000.00. After
45 days, AAK sent out 10 hydraulic pressure control valve samples.

Yesterday, Els emailed us a PO for 500 hydraulic pressure control valves. The
functions of AAK hydraulic pressure control valves meet their equipment
requirements, and energy consumption has been reduced by 20%. There will be no
problem that the equipment will sell well. AAK hydraulic pressure control valve
is connected to the control of internal and external flow diversion, and
together with the control of internal and external discharge flow, the original
90 ° guide flow is optimized to 180 ° direct flow.

1. The valve spool of AAK hydraulic pressure control valve is a tubular lifting
type with a sliding control sleeve, exposing the radial hole in the valve spool
and entering the open position, sealing the radial hole to enter the closed
position.

2. The tubular lifting valve spool is connected to the threaded end, and the
outer diameter of the valve spool extends to the radial orientation hole of the
inner diameter. The hole faces forward from the inner side to the outer side at
a 180 degree angle, making fluid flow smoother.

3. The control sleeve is connected to the spring wrapped around the tubular
lifting valve spool, and there is an oil groove for aligning the control sleeve
in the corresponding hole in the valve body. The control sleeve can slide along
the length of the tubular lifting valve spool between the seat and the
retaining ring.

AAK hydraulic pressure control valve, reduces energy consumption, and is also
durable. You can give it a try!
