6 Layer Impedance Plate Automobile Smt Printed Circuit Board Halogen Free
PRODUCT DESCRIPTION
6-layer impedance plate automobile plate halogen-free multilayer plate
Essential details
Model Number:
PCB
Type:
rigid pcb, Electronic Board
Place of Origin:
Guangdong, China
Brand Name:
Customized
Base Material:
FR4 /aluminum/ceramic CEM
Copper Thickness:
0.5-4OZ / 1Oz / 2Oz or Custom
Board Thickness:
0.2~6mm
Min. Hole Size:
T / 2mm / 0.2 Mm / 0.15mm or Custom
Min. Line Width:
0.15mm / 0.1mm/ 4mil or Custom
Min. Line Spacing:
0.15mm / 0.1mm or Custom
Surface Finishing:
HASL/Immersion gold/Flash gold/plated silver/OSP
Board Size:
Customized color and size, Max 1200mm
Material:
FR4 /aluminum/ceramic CEM1
Solder mask color:
Blue.green.red.black.white.etc
Layer: ,
1~24 Layers
MOQ:
1pcs
Testing service:
AOI X-RAY Function Test
PCB Item:
94v0 Fr4/aluminum Pcb
Product name:
Pcb Board Assembly
Application:
Electronics Device
capability
Specification of PCB Manufacturing
Layer
1~32 Layers
Material
FR4,CEM1,CEM3,Hight TG,Rogers,F4B,Taconic,FR1,FR2,94v0,Aluuminum
Or , der Quanyity
1~500,000
Board shape
Rectangular,Round,Slots,Cutouts,Complex,I , rregular
Board Cutting
Shear,V-score,Tab-routed,Counter sunk
Board thickness
0.2~8.0mm,Flex0.01~0.25“
Copper weight
0.5oZ~12oZ
Solder mask
Double-sided green LPI,Also support red,white,yellow,blue,black,purple,etc
Silk screen
Double-sided or single-sided in white,yellow,red,black,or negative
Min line width/space
0.06/0.06mm
Max board dimensions
25.6 inch*43.3 inch or 650mm*1100mm
Min drill hole diameter
0.1mm
Surface finish
HASL,ENIG,Immission Ti,Immisson Silver,OSp,ENEPIG,etc
Board thickness tolerance
±10%
Minimal slot width
0.12",3.0mm,or 120 mils
V-score depth
20~25% of board thickness
PTH Wall Thinckness
>0.025mm
PTH Hole Dia Tolerance
±0.076mm
Non PTH Hole Dia Tolerance
±0.05mm
Hole Position Deviation
±0.076mm
Sink holes
Yes
Quality Standard
IPC-A600F/MIL-STD-1050D
Design file format
Ki-CAD,Pro-E Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG
Our products are widely used, included
Automotive, Medical Device, Consumer Electronics, Aerospace, Digital
Communications, Industrial Control and more
6 Layer Impedance Plate Automobile Smt Printed Circuit Board Halogen Free 0
)
