500L Column Still Vodka Gin Distillation Equipment Copper Distiller

Copper provides an essential chemical reaction, especially at lower standards,
which can remove sulfides when alcohol is in vapor form. Copper has the ability
to react with many sulfides, such as sulfides or mercaptans, which are usually
present in the fermented mash, making them insoluble and removing them from
high wine vapors.

Composition of 500L distillation equipment
500L distillation tank, explosion-proof stirring motor, all-glass manhole.
Helmet copper whiskey helmet.
16 pieces of pillar copper.
Condenser column made of copper, pipe and shell type.
The support base is made of SS, and the water tank and product tank are used as
the support base.
Distillation pot: inner full copper pot, outer steam jacket insulation layer,
outer fish scale polished, full glass manhole view, stirring with agitator on
the top.
Column board: full CU122 copper foam board, operated with a valve on the side,
CIP ball inserted into each board for cleaning, and operated with CIP pipes and
valves on the back.
Bottom collection tank: The water tank collects condensate water and uses CIP
to clean it, the alcohol tank is collected directly from the parrot, and the
bottom is connected to a water pump.
Blister: Composed of blister, drain pipe, bubble plate, red copper screw,
bubble tee (we have stainless steel 304 and red copper optional).
Control panel: The material of the control box is stainless steel 304 or
plastic optional.
Applicable voltage: 208/220/240V single-phase 60Hz, heating temperature can be
adjusted by module.
The water outlet adopts a high hygienic glass cover, with a copper cover on the
top, a straight opening type, and a valve at the bottom.
