3V120-06 Directional Control Valve

3V120-06 Directional Control Valve
Product Description
High Flow Rates: Designed to handle high flow rates, ensuring efficient
operation in various applications.
Robust Construction: Durable build to withstand challenging industrial
environments.
Double or Single Solenoid Operation: Options for either double solenoid for
bistable operation or single solenoid for spring return functionality.
Multiple Mounting Options: Can be base mounted, sub-base mounted, or manifold
mounted for flexibility in installation.
Manual Override Option: Often includes a manual override for troubleshooting or
manual operation in case of power failure.
Parameter
Mode 4V110-M5 4V120-M5 4V130C-M5 4V130E-M5 4V130P-
M5 4V110-06 4V120-06 4V130C-06 4V130E-06 4V130P-
06
4A110-M5 4A120-M5 4A130C-M5 4A130E-M5 4A130P-
M5 4A110-06 4A120-06 4A130C-06 4A130E-06 4A130P-
06
Type 5/2 5/3 5/2 5/3
Flow rate 10mm2（Cv=0.56） 7mm2（Cv=0.40） 12mm2（Cv=0.67）
9mm2（Cv=0.5）
Model 3V110-M5 3V120-M5 3A110-M5 3A120-M5 3V110-
06 3V120-06 3A110-06 3A120-06
Type 3/2 3/2
Flow rate 10mm2（Cv=0.56） 12mm2（Cv=0.67）
Connection ports Inlet = Outlet = Exhaust = M5x0.8 Inlet = Outlet
= Exhaust = G1/8"
