3 Ways Sanitary Pneumatic Divert Valves Diversion Control

Sanitary Pneumatic 3 Ways Divert Valves Diversion Control Valve


Specifications

Product Name:

BPE 3 way Diaphragm valves for Phamcy /SS316L DONJOY membrane valve

Valve Body Material:

SS316L

Seal Material:

Single sillcone gasket/ Adhesive PTFE+EPDM/Two pieces PTFE+EPDM

MaxWorking Pressure:

6 Bar

Max.Working Temperature:

120 degree C

Availably size:

3/4''-2.5'', DN20-DN65

Availably connection:

Clamp/weld/thread/special connection

Availably standard:

3A/BPE/DIN/ISO/IDF

Operate , d:

Manual,Pneumatic

Availably structure:

Straight, tee, U-type, tank bottom

Control:

Smart valve positioner / C-TOP control / position sensor

Certificate:

3A/54-02 (1580), PED/97/23/EC, FDA.177.2600

Application scope:

Dairy,food, beverage, pharmacy, cosmetic, etc

Logo of product:

With "DONJOY" or customized

Combination of valve and actuator:

Flexible combination on valve body


Description
Various configuration of Diaphragm valve
1. Didaphragm valve with Pisitioner/Process Controller(IL-TOP)
2. Diaphragm valve with Control Unit(C-Top)
3. Valve position Regulator
4. Position Sensor Module
5. Plastic Handle
6. Stainless steel handle
7. Stianless steel acutor
8. Electric Diaphragm valve

9. Plastic actuator
3 Ways Sanitary Pneumatic Divert Valves Diversion Control 0



Usage of Diaphragm Valves

The diaphragm valve can be used with corrosive liquids at low temperatures and
pressures. These valves can be used for potable water, air, sludge, chemicals,
as well as low-velocity slurries and effluents. They can be installed near
pumps and bends, as well as vertical pipelines.

Common Applications of Diaphragm Valves

Diaphragm valves are widely used in many industries due to their affordability,
effectiveness, and variety. There are a host of possible applications for
diaphragm valves, but here are some of the most common:

Advantages of Diaphragm Valves

This valve has the best corrosion resistance or abrasion resistance that we
could find.
There is no steam leakage.
They are suitable for use with hazardous chemicals and radioactive fluids.
Food and pharmaceutical processing use these valves since they won't allow
contamination of the flow medium.
The valves are simple in construction and easy to operate.
3 Ways Sanitary Pneumatic Divert Valves Diversion Control
Enlarge Click to Enlarge
