2.5 inch Tubing swage Wireline Tool String

I. Introduction

Tubing swage is a tool to shape the changed diameter of to guarantee that the
downhole device can pass smoothly or to get through the flavedo-type blocks at
the end of tubing.

II. General Technical Parameters

OD Fishing neck Connection t PN
1.25＂-1.5＂ 1.187＂ 15/16-10UN W21-03.**.00
1.5＂-2＂ 1.375＂ 15/16-10UN W21-03.**.00
2＂-2.5＂ 1.375＂ 15/16-10UN W21-03.**.00
2.5＂-3＂ 1.75＂ 1-1/16-10UN W21-03.**.00
3＂-4＂ 1.75＂ 1-1/16-10UN W21-03.**.00
4＂-5＂ 2.313＂ 1-9/16-10UN W21-03.**.00
Note:more customized parts are available upon request.

III. Structural features:

The top of the tubing swage has external threads (or quick male joint) and
fishing neck; the inner diameter of waist is about equal to that of the
deformed oil pipe, so there are air holes or drain holes in the middle, and the
pipe tapers off from the middle to both ends; the bottom also can be processed
with threads to connect with tools. The whole body of tubing swage is made of
alloy steel, and the hardness of the part for shaping reaches 43～45HRC through
quenching and tempering.
