2.4GHz 3dBi Black Omni Antenna Magnetic Mount Vehicle Mobile Antenna (AC-Q2

2.4 ghz high gain directional antenna delivers marked improvements in
efficiency and gain across all common frequencies（2400-2483MHz) in use for
WIFI and Wireless bands.

Small enough to be used indoors and outdoors, the antenna performance has been
designed to take advantage of any metal plate (ground-plane) it attaches to
deliver best of class performance.

After capturing the signal, the installation method of automatic pasting is
adopted to prevent it from being easily moved, ensuring the reception effect.

Specification of 2.4 ghz mobile antenna
Electrical
Frequency Range 2400-2483MHz
Band width 83MHz
Gain 3dBi
V.S.W.R ≤2.0
Radiation Omni-Direction
Polarization Vertical
Maximum Input Power 50W
Impedance 50Ώ
Connector SMA Male(can be customization)
Cable Type RG174
Cable Length 3M
Antenna Radome Material ABS
Mounting way Self Adhesive
Mechanical
Dimensions 22x115mm
Weight 45g
Operating Temperature -40℃ to+70℃
RoHS Compliant YES


Features of 2.4 ghz long range wifi antenna
01
This antenna can be work for U-NII and ISM applications.

02
2.4 GHz antenna working for ISM applications such as Internet of Things (IoT)
devices.

03
Antenna Compatible with 2.4GHz FPV Camera Monitor, FPV Drone Racing Quadcopeter
Controller.

For more information about helical rf antenna, please feel free to contact us!
