12kV Transformer Capacitance &Tan Delta Tester

Highly accurate loss angle tangent/power factor measurement equipment is used
to measure very low dielectric losses in high voltage equipment. Loss Angle
Tangent/Power Factor is an accurate and non-destructive method of providing
important information about the degree of deterioration of an insulation
system. Tests are performed during regular maintenance and inspection of high
voltage equipment such as power transformers, transformers, bushings,
capacitors, motors, generators, power cables, and other high voltage equipment.
Hengfeng capacitance and tan delta tester measures the capacitance and
dielectric loss factor (tgδ) of high voltage electric equipment.
Features
1. 7" high resolution color touch screen.
3. Multiple automatic double vairable frequency , which can effectively resist
the frequency interference of test site and ensure the accuracy and stablity of
test results.
3. UST+GST+CVT+ GSTg+ CVT ratio + polarity+phase difference+4 channels
4. 4-channel function, measuring four test object in a single test
5. Reserve the interface for external standard capacitor and external
transformer
6. Internal memory with time/date stamp
7. Internalthermal printer
8. USB port for export test data to USB flash drive.
