129 Adjustable Short Tee Adjustable Short Tee Suppliers

129 Adjustable Short Tee Adjustable Short Tee Suppliers Three Way Elbow
Supplier

Product Description
Malleable iron pipe clamps fittings
Our product is manufactured according to the requirements of EN-GJMB-300-6 with
tensile strength min 300 N/mm2 and elongation min 6%. Usually the real tensile
strength is higher than 300, it may reach to 330 and the elongation may reach
to 8%. That is to say our material is between EN-GJMB-300-6 and EN-GJMB-330-8.

Usage: Malleable iron pipe clamps fittings used to connect steel tubing,
different rang of fittings can combined with standard tubing enables the users
to create any structure imaginable for use in all manner of industries, such as
handrail fittings, shelving, car ports, shopping trolley bays, support
frameworks, outdoor sport, exhibition stands, play areas and so on. Instead of
the orginal welding method, the tube can be quickly connected with only a
simple allen key, which is more simple and convenient. You should select the
correct fittings and size for any application. If you want to know more
technical support or assistance regarding the use and interpretation of the
those products, pls contact us.

Material: ASTM A 197
Surface: Hot dip galvanized /Electroplating
Specification:
Pipe Clamp size Nominal Bore Outside Diameter
T21 1/2" 21.3mm
A27 3/4" 26.9mm
B34 1" 33.7mm
C42 1-1/4" 42.4mm
D48 1-1/2" 48.3mm
E60 2" 60.3mm

MILL TEST REPORT
Description: Malleable Iron Pipe Clamps Fittings with BSP Threads

Description Chemical Properties Physical Properties
Lot No. C Si Mn P S Tensile Strength
Elongation
ALL PALLET 2.76 1.65 0.55 LESS THAN 0.07 LESS THAN 0.15 300 Mpa
6%

Terms payments: TT 30% prepayments of products before producing and TT the
balance after receiving copy of B/L, all price expressed in USD;
Packing detail: Packed in cartons then on pallets;
Delivery date: 60days after receiving 30% prepayments and also confirming
samples;
Quantity tolerance: 15%.

Shijiazhuang Donghuan Malleable Iron Castings Co.,ltd supplies Malleable iron
fittings, Ductile iron fittings, Gray iron fittings and other steel products,
with a long history and unchanging faith in producing high-quality products.
